Product Price : $163.00 Product Tax : $174.41
NextGen 3000™ Universal Guardrail is a state-of-the-art, non-penetrating, modular rooftop safety railing system. It's OSHA compliant and outperforms all other roof fall protection products.
NextGen 3000™ Universal Rails are available in pre-assembled 5ft. (14lbs), 7.5ft. (21 lbs.) and 10ft. (29 lbs.) steel panels. All rails are 42 inches in height.
NextGen 3000™ Standard Bases with Hitchpins are designed to specifically fit with the NextGen 3000™ Universal Rails. NextGen 3000™ Universal Bases with Clamps can be used with different sized railing as well as NextGen 3000™ Rails. Each base weighs only 58 lbs. The system is free-standing & non-penetrating so it won't damage the roof membrane.
Rails and Bases are available in Galvanized finish or durable TS-22 coating - Yellow finish is standard and custom colors are available. Note: Toe Boards / Kick Plates are also available.
Note: Minimum 5 ft. returns are required at terminations to satisfy OSHA standards.
Contact Us for design assistance. Financing available (3/6/12 months) thru online purchase.
Features: OSHA compliant engineered design Lightweight, stackable bases with grab handles Bases designed with neoprene rubber feet High quality / Low cost Simple installation
Technical Specifications: Tested to exceed OSHA Standards 58 lbs. steel bases Pre-assembled 1.66 OD panels (5ft, 7.5ft, 10ft) NG-22 Coating - Yellow Finish (other colors available) or Galvanized finish
Installation: Tie-off according to OSHA Standards Remove stones from roof at base location Place bases 18 in. from the roof edge Insert railing panels into base sockets Secure railing to base using hitch pin Install 5 ft. returns at terminations
Flier
Railing w/ Standard Bases Installation Instructions
Railing w/ Universal Bases Installation Instructions
Technical Specifications / Cut Sheet
Collapsible Rail Cut Sheet
CAD / Sample Layout
Base Dimensions
OSHA Testing
Wind Load Analysis
Warranty
