KeeGuard® Railing

KeeGuard Short Run Attached to Structure

KeeGuard Short Run Attached to Structure Close

KeeGuard® Railing

Request Quote

KeeGuard® roof edge fall protection railing utilizes a counterbalance weighted system installed along the roof edge. It is free standing and uses recycled PVC weights as ballasts. KeeGuard Railing is designed for flat or low slope roofs. It can be used on slopes up to 1/12 pitch (5 degrees). The railings extend above the walking surface 42” and withstand a force of 200 pounds. There’s no need for drilling, welding, or fastening into your roof.

Its configuration accommodates varying angles, circular configurations, ladders, and rooftop obstructions. KeeGuard Railing exceeds OSHA Standard 1910.28(b)(13) and meets all North American and Canadian requirements. Note: Base / Membrane Pads are also available.

Features:

OSHA compliant design

Free-standing ballast system

"Green" reconstituted PVC weights

Neoprene pad glued to the post base

Accommodates angles and rooftop obstructions

Infill Panels available

Kick Plates available

Materials:

Pipe is ASTM A53 1-1/2-inch schedule 40 galvanized steel

Fittings are galvanized KeeKlamp® malleable iron-type

Mounting bases are galvanized steel with neoprene rubber pad

Counterweights are "green" recycled PVC

Installation:

PVC counterbalance bases are assembled based on instructions

Pre-assembles posts are inserted into Bases

Galvanized top and mid railings are saddled between posts

Note: 3 workers can install greater than 300 feet per day. Shop drawings can be provided if needed

Flier

Installation Instructions

Warranty
